- Digital Crossover with 24x32-bit high speed signal processor
- 2 In/4 Out - 1U 19-inch rack-mount
- High-quality BurrBrown 20-bit A/D and 24 D/A converters for pure and clean audio quality
- Open architecture for easy software updates
- Windows editor for powerful and simple PC based MIDI remote control
- Linkable in "cascade" mode with other units
- 64 user presets available
- 5 PEQ for each channel
- Band pass filter available (up to 24dB/Oct) for each output channel
- Polarity (switchable 0° or 180° for each output channel)
- Limiter/Compressor for each output channel
- Input and output digital volume
- Full "routing" possibilities between inputs and outputs
- Up to 0.5 sec. of delay per channel by step from 21ms to 2 ms
- "Lock-system" for the editing functions
- 128x64 backlit graphic display for clear readability
- Servo-balanced inputs and outputs with XLR and 1/4" TRS connectors
- Manufactured under ISO9000 certified management system
