UF-20R/UF-20TB * 2 Wireless dual system with pocket transmitter

With the UF-20 True Diversity wideband System, JTS takes a big step into the High End world. Nothing has been spared here. The system is aimed at those who want the very best. Here are some key points to consider.

• 70 MHz Bandwidth in the frequency range 624 - 694 MHz.
• 15 pre-programmed groups of 63 internally interference-free frequencies each.
• 6 groups with 64 frequency slots each for own programming.
• 10mW - 50mW adjustable output power, Up to 480M range.
• Multi-color display warns with red color for No RF, Transmitter in Mute, low battery level on transmitter.
• Self-scanning, the receiver itself searches for a group of free frequencies.
• Transmitter and receiver are locked to each other with ID numbers. • The receiver's programming with e.g. Frequency, channel, EQ, User name, ID, Antenna power, etc. sent with Remoset via radio to the transmitter (range approx. 100m).
• Built-in Antenna distributor, up to 10 units can be connected in cascade, Antenna cables included.
• The power can be cascaded with an unlimited number of devices, patch power cable included.
• As accessories there are chargers for 2 units and charging case for 8 units, RTF-UF20 cables & connectors for front mounting of antennas. FC-5U & FC-5UD flight cases.

This system contains: 1 double receiver, 1 pair of rack angles, 2 Pocket transmitters in bag. 1 mains cable, 1 patch mains cable, 2 antenna cables for cascade connection, 2 long antennas, user manual.

Chargers for 2 transmitters are available as accessories:

• JSS-20CH2 or 8 transmitters JSS-20CH8
• Display LCD.
• Display Contents Group, Channel, Frequency, Battery Level, Antenna A/B, Mute Display, AF Meter,
• RF Meter, Frequency Scan, Audio Level, Volume, Controls Power ON/OFF, Group, Channel, Frequency,
• Mute Display, Key Lock, Volume, Output Attenuaiton(XLR), Frequency Scan(ON/OFF).
• Audio Output Level Ref/ ±22.5KHz Dev@1KHz Tone.
• 6.3 Phone Jack/ -10dBV.
• XLR Jack/ -4dBV(Line) ? -24dBV(MIC).
• Audio Output Impedance 600O.
• Squelch Pilot Tone & Noise Mute.
• Output Connector 1 independent balanced XLR and one Ø6.3mm unbalanced.
• Power Supply DC12~15V/300mA.
• Dimension (mm) 212.3mm(W)* 38.3mm(H)* 144mm(D).
